| d1 | d5 | h | d3 | h4 |
| M10 | 19 | 7 | 13 | 2,25 |
| M13 | 25 | 8 | 17 | 3 |
| M16 | 32 | 8 | 21 | 4,5 |
| M19 | 32 | 10 | 23 | 6 |
| M22 | 35 | 10 | 29 | 6 |
| M25 | 41 | 12 | 31 | 7 |
Ceramic Ferrule for Threaded Stud (PF)
| From | d + 0.5 | d8 +/- 1 | d9 +/- 1 | h2 |
| PF 06 | 5.6 | 9.5 | 11.5 | 6.5 |
| PF 08 | 7.4 | 11.5 | 15 | 6.5 |
| PF 10 | 9.2 | 15 | 17.8 | 6.5 |
| PF 12 | 11.1 | 16.5 | 20 | 9 |
| PF 16 | 15.0 | 20 | 26 | 11 |
| PF 20 | 18.6 | 30.7 | 33.8 | 10 |
| PF 24 | 22.8 | 30.7 | 38.5 | 18.5 |
Welding Shear Connecting Stud: Key Features and Applications
Welding shear connecting studs are specialized fasteners designed to provide strong, permanent connections in various structural and industrial applications. These studs are essential for creating secure shear connections between metal components, often used in welding and construction projects where high strength and durability are required. At Pankaj International, a leading fastener manufacturer in Ludhiana, we produce high-quality welding shear connecting studs that adhere to rigorous industry standards, ensuring their effectiveness and reliability in demanding environments.
Precision Engineering for Shear Strength
Welding shear connecting studs are engineered to offer exceptional shear strength, making them ideal for applications where high shear forces are present. These studs are typically made from high-grade materials such as alloy steel or stainless steel, which provide excellent tensile strength and resistance to deformation. The design of the welding shear connecting stud includes a cylindrical body with a welded end, allowing for secure attachment to metal surfaces. The welded end ensures that the stud remains firmly in place, providing a reliable connection that can withstand significant shear forces. At Pankaj International, our welding shear connecting studs are meticulously crafted to deliver the strength and stability needed for critical structural applications.
Durability and Corrosion Resistance
Given their exposure to harsh conditions and environmental factors, welding shear connecting studs must be highly durable and resistant to corrosion. To ensure long-lasting performance, our studs are manufactured from high-quality materials and treated with protective coatings such as zinc plating or hot-dip galvanization. These coatings enhance the studs' resistance to rust and corrosion, making them suitable for use in outdoor and industrial environments where exposure to moisture and other corrosive elements is a concern. This durability reduces the need for frequent maintenance and ensures that the studs remain effective over time.
Conclusion
Welding shear connecting studs are essential for creating strong and reliable shear connections in structural and industrial applications. Their robust design and high durability make them ideal for use in welding and construction projects where secure and permanent fastening is crucial. At Pankaj International, we are dedicated to producing high-quality welding shear connecting studs that meet the highest standards of performance and reliability. Whether you are involved in construction, manufacturing, or other industrial applications, our studs provide the strength and durability required to ensure the success of your projects. Contact us today to learn more about our range of fasteners and how we can support your specific requirements
